Air Platform

Airfloat Air Platforms allow an operator to efficiently move pallets or any heavy or difficult to handle load up to hundreds of thousands of pounds with ease. Using our Air Caster technology, Air Platforms provide near friction-free movement in any direction, giving them an advantage to wheeled carts and forklifts for moving pallets and heavy loads. Our platforms also feature a retractable guide wheel, which makes the maneuvering of large loads by the operator easier.
